Vishay P3 User Manual

- 5 -
2.5 Measurement Range/Resolution
Strain Range: ±31,000 µε at GF = 2.000. (±15.5 mV/V)
Resolution: ±1 µε at GF = 2.000 (±0.0005 mV/V)
2.6 Measurement Accuracy
±0.1% of reading ±3 counts. (Analog output disabled,
instrument Gage Factor = 2.000)
2.7 Gage Factor Control
Range: 0.500 to 9.900
2.8 Balance Control
Type: Software
Control: Manual or automatic
2.9 Bridge Excitation
Value: 1.5 VDC nominal
Control: Software enable/disable
Measurements are fully ratiometric, and not degraded by
variations in excitation voltage
2.10 Communication Interface
Universal serial bus (USB). Cable included
2.11 Data Storage
Type: Removable Multimedia Card (16M supplied).
Recording rate: Software-selectable from 1 reading per
second to 1 reading per hour
2.12 Shunt Calibration
Location: Across bridge completion resistors
