- 4 -
2 SPECIFICATIONS
Note: Performance may be degraded at high levels of repetitive electrostatic
discharge; however, no damage to the unit will occur.
2.1 Input Connections
Type: Tool-free eccentric lever release
Quantity: Four
Wire size: 16 to 28 AWG [1.29 to 0.31mm Φ]
2.2 Bridge Configurations
Types: Quarter-, half-, and full bridges
Bridge Impedance: 60 to 2000 Ω
Internal Bridge Completion:
Quarter bridge: 120Ω, 350Ω and 1000Ω ±0.01%
Half bridge: 1000Ω ±0.01%
2.3 Display
Type: 128 x 64 pixel FSTN positive, gray transflective
LCD with backlight
Update rate: 2 updates/second typ.
2.4 Data Conversion
A/D Converter: Delta-sigma with integral chopper-
stabilized programmable gain instrumentation amplifier
Resolution: 24 bits. Noise-free resolution: 18 bits typ.
Output rate:
Normal mode: 50 or 60 samples/sec.
Analog output mode: 480 samples/sec.
Filter: Integrated linear phase FIR Sinc
5
filter followed
by a Sinc
3
filter with a programmable decimation rate.
Software selectable output rate provides >120 dB rejec-
tion of 50 or 60Hz and higher level harmonics.
