- 38 -
The system will make another series of measurements, validate
the readings, and, if valid, will display the next step:
SYSTEM CALIBRATION
Set calibrator to
-30000 microstrain
CAL = Calibrate
Set the 1550A calibrator to -30000 (negative polarity), and
press the key.
Finally, the system needs to establish a true electrical zero (amp
zero).
SYSTEM CALIBRATION
Set calibrator to
S+/S- short
CAL = Calibrate
Short the S+ and S- terminals on the 1550A calibrator and press
the key.
This process will repeat on the remaining three channels. Once
the calibration process is complete, the system will store the
