Appendix B: Master-Slave Protocol
VT400 Technical Manual, Rev. A5 78 Doc # UM-VT400-EN
$ and + Commands: Download/Upload D/A Setup and Zero (1)
New settings do not go into effect until a Write to EEPROM (*) command is issued.
Data Byte
Number
Parameter
to be Set
Name Description
W1 A.1-A.8
(b0-b7)
A.1
A.2
A.3
A.4
A.5
A.6
A.7
A.8
b0
b1
b2
b3
b4
b5
b6
b7
W2 - Analog output
0
2 most significant
digits, ASCII hex (no
decimal point)
W3 - Analog output
0
2 least significant
digits, ASCII hex (no
decimal point)
% and , Commands: Download/Upload D/A Full (1)
New settings do not go into effect until a Write to EEPROM (*) command is issued.
Data Byte
Number
Parameter
to be Set
Name Description
W1 2, 2L Linefeeds after
printout
2 digits (ASCII) hex
W2 - Analog output
FULL
2 most significant
digits, ASCII hex (no
decimal point)
W3 - Analog output
FULL
2 least significant
digits, ASCII hex (no
decimal point)
