Vishay VT400 - Master-Slave Command Details (Enable & Errors); 7 Command: Enable Setpoint Outputs; 8 Command: Upload Error Code

Appendix B: Master-Slave Protocol
VT400 Technical Manual, Rev. A5 79 Doc # UM-VT400-EN
& and - Commands: Download/Upload Setup 1, 2, 3
Data Byte
Number
Parameter
to be Set
Parameter Bit Command Word Bit
W1 SETUP 1 1.1
1.2
1.3
1.4
1.5
1.6
1.7
1.8
b0
b1
b2
b3
b4
b5
b6
b7
W2 SETUP 2 2.1
2.2
2.3
2.4
2.5
2.6
2.7
2.8
b0
b1
b2
b3
b4
b5
b6
b7
W3 SETUP 3 3.1
3.2
3.3
3.4
3.5
3.6
3.7
3.8
b0
b1
b2
b3
b4
b5
b6
b7
` and . Commands: Download/Upload Setup 4,5
Data Byte
Number
Parameter
to be Set
Parameter Bit Command Word Bit
W1 SETUP 4 4.1
4.2
4.3
4.4
4.5
4.6
4.7
4.8
b0
b1
b2
b3
b4
b5
b6
b7
