6 Commissioning
ENGLISH
DO_BA_2008_121LB_3ENG_BVo 22.2.10
16.Press the button and hold it for longer to confirm the entry.
Result The inverter is commissioned.
If the inverter does not supply current, check the installation.
Make sure that
| Wires are correctly connected to the mains power supply.
| All cables are connected tightly.
| The solar power system polarity and voltage are correct.
| Position of the DC switch connector is correct.
LED indicators during commissioning
In parallel to commissioning, the inverter activates the LED
indicators.
Selecting the language sets a country-specific set of
parameters. The manufacturer has defined country-specific
parameter sets in line with country-specific standards. You
only have a period of 5 minutes after commissioning in which
to select a different country with its corresponding parameter
set. To do this, use the button to navigate to the SERVICE
menu. This setting can then be changed only via
StringInverter Setup.
The inverter functions only if a set of parameters is set.
If you want to use the device in a country that is not listed in
the display, contact the manufacturer's service centre
(contact information on the back of the manual).
COUNTRY
GERMANY
Ready Solar Gen-
erator
Grid Fault Meaning
U
SG
≥ 200 V
DC
Internal electronics are not
yet powered sufficiently.
30–40 seconds may elapse before LED test.
Test of the LED indicators
The inverter does not have a parameter set
and is not therefore operational
