76
Lubrication system
Repair Instructions
Oil filter, replacement (18A-01)
1
Place a container under the filter to collect any
spilled fluid.
2
7
Check that there is lubricating oil in the oil pan.
8
Start the engine and check the filter for leaks.
Check the oil level on the dipstick when the engine
has cooled and top up the oil in the oil pan if neces-
sary.
NOTE! The filter holder contains a valve and a spe-
cial pipe which ensures that the filter is not drained
of oil. Ensure that the correct type of filter holder is
used.
Remove the filter holder with a strap wrench or a
similar tool. Ensure that the adapter (A1) remains in
the filter head and discard the holder.
3
Clean the filter head.
4
Fill the new reservoir with fresh engine oil. Give the
oil time to fill the holder through the filter element.
5
Lubricate the upper side of the filter holder gasket
with fresh engine oil.
6
Install the new filter holder, hand tighten only. Do
not use a strap wrench.
Oil filter adapter, replacement
(18A-02)
1
Place a container under the filter to collect any
spilled fluid.
2
Remove the oil filter, operation 18A-01.
3
Install the pipe to the oil cooler if required.
4
Unscrew the mounting screws and remove the oil
filter adapter from the oil pump. Discard the gasket.
