Service and maintenance
Cooling system 127
Water pump, checking belt
The engine features two coolant (water) pumps, each with a flat
belt of Poly-V type. They have automatic belt tensioning.
NOTE! The belt guard has been removed in the picture.
Check the condition of the belt every 2000 hours.
Change belt if any of the belt's ribs is missing.
1
7
2
A
1007821
B
A Secondary water pump
B Primary water pump
