Specifications
Engine, specifications 173
Engine, specifications
Air cleaner
A25E A30E
Make Volvo
Designation D9B D9B
Flywheel output at 35 r/s (2100 rpm) 224 kW SAE J1349 Gross 252 kW SAE J1349 Gross
Torque at 20 r/s (1200 rpm)
SAE J1349 Gross
SAE J 1349 Net
DIN 6271*
1700 N m (1254 lbf ft)
1689 N m (1246 lbf ft)
1689 N m (1246 lbf ft)
1700 N m (1254 lbf ft)
1689 N m (1246 lbf ft)
1689 N m (1246 lbf ft)
*) with the cooling fan running at basic speed. With the fan at maximum speed the generated torque is 1589 Nm, which
corresponds to DIN 70020.
Number of cylinders 6 6
Cylinder bore 120 mm (4.724 in) 120 mm (4.724 in)
Stroke 138 mm (5.433 in) 138 mm (5.433 in)
Cylinder capacity, total 9.4 litres (573.6 in
3
) 9.4 litres (573.6 in
3
)
Compression ratio 19.2:1 19.2:1
Order of injection 1-5-3-6-2-4 1-5-3-6-2-4
Idle speed, low 700 ±10 rpm (11.7 r/s ±0.2) 700 ±10 rpm (11.7 r/s ±0.2)
Idle speed, high 2200 rpm (36.7 r/s) 2200 rpm (36.7 r/s)
Valve clearance, cold engine
Inlet
Exhaust
0.20 mm (0.008 in)
0.80 mm (0.031 in)
0.20 mm (0.008 in)
0.80 mm (0.031 in)
Oil pressure, min. at low idle rpm (warm engine) 270 kPa (2.7 bar) (39 psi) 270 kPa (2.7 bar) (39 psi)
Oil pressure, min. at high idle rpm (warm engine) 300–550 kPa (3.0–5.5 bar)
(44–80 psi)
300–550 kPa (3.0–5.5 bar)
(44–80 psi)
Type Dry filter together with secondary filter
Pre filter Cyclone cleaner
Oil bath air cleaner (market-adapted equipment)
