Instrument panels
Right instrument panel 27
6 Delayed stop of engine (optional equipment)
Upper end of switch pressed in = delayed stop deactivated
Lower end of switch pressed in = delayed stop activated (lamp in
switch lights) and the function will be connected if the following
conditions are met:
– gear selector in neutral (N position)
– the start key in position 0 (OFF) or position R (radio position)
– the switch is on.
7 Hazard flashers
NOTE! May only be used if you are forced to stop the machine
in a way that constitutes a danger to other road users.
Upper end of switch pressed in = hazard flashers switched off
Lower end of switch pressed in = hazard flashers switched on
8 Rotating warning beacon (optional equipment)
Upper end of switch pressed in = rotating warning beacon
switched off
Lower end of switch pressed in = rotating warning beacon
switched on
9 Electrically heated rear view mirrors
(optional equipment)
Upper end of switch pressed in = heating switched off
Lower end of switch pressed in = heating switched on
10 Electrically heated seat (optional equipment)
Upper end of switch pressed in = heating switched off
Lower end of switch pressed in = heating switched on
11 Raised engine speed (optional equipment)
Upper end of switch pressed in = raised engine speed turned off
Lower end of switch pressed in = raised engine speed switched on
The operating speed control function will be engaged provided that
the following conditions are met:
– The function operating speed is activated from the service
display unit or VCADS Pro.
– No gear engaged (transmission in neutral).
– Lower end of switch pressed in. Switch is on.
A9002600
STOP
A9002800
A9002900
A9002400
A9002300
A9002700
r/min
