Other controls
Controls 47
1 Retarder in brake pedal
Upper end of switch pressed in = disengaged retarder
Lower end of switch pressed in = engaged retarder (light in switch
is on). See also page 70.
2 Exhaust braking in accelerator pedal
Upper end of switch pressed in = limited engine braking
deactivated.
Lower end of switch pressed in = limited engine braking in
accelerator pedal activated and the function will be engaged
automatically when the accelerator pedal is released.
3 Gear-shift inhibitor
The switch is a rocker-switch. The light in the switch is on when the
gear-shift inhibitor is engaged. See also page 63.
4 Gear selector
NOTE! Never leave the machine with the gear selector in
forward or reverse, while the engine is running.
Gear positions
Position 1 1st gear
Position 2 Aut. shifting between 1st and 2nd gear
Position 3 Aut. shifting between 1st, 2nd, and 3rd gear
Position D Aut. shifting between 1st, 2nd, 3rd, 4th, 5th,
and 6th gear
Position N Neutral
Position R Aut. shifting between 1st and 2nd reverse gear
See also page 63.
A9001700
A9001800
A9001900
