Operating instructions
80 Transporting the machine
Lifting machine
The lifting tools are optional equipment to be used for lifting
the machine. They are intended for a machine weight of:
– MAX. 24500 kg (54010 lb) for A25E 6x6
– MAX. 21900 kg (48280 lb) for A25E 4x4
– MAX. 26900 kg (59300 lb) for A30E
Lifting tool, (optional equipment)
Q It is important to use the right lifting tools and nuts, contact a
dealer authorised by Volvo CE for the right tools. The
combination of rims and tyres determines which tools and nuts
are to be used.
Q It is important that lifting tools are installed correctly, contact a
dealer authorised by Volvo CE for the right method.
Q The lifting tool should only be installed on the machine for lifting
and transporting. Remove the tool after use.
Q The nuts belonging to the lifting tool should preferably be stored
on the tool when they are not used.
Q The ordinary wheel nuts should not be stored on the tool when
the tool is installed on the machine.
Q The lifting tool is marked with two decals that state which tool
and nuts should be used in combination with a certain rim and
tyre. The part number is also stamped-in on the lifting tool itself.
Tightening torque for nuts for lifting tool, 200 Nm.
WARNING!
Never remain under the machine when it is suspended in
the air.
WARNING!
Do not lift the machine using the eyes on the dump body.
WARNING!
The lifting tool must only be installed together with the
special nuts supplied together with the tool, otherwise the
tool may loosen causing serious damage.When removing
the tool, the ordinary wheel nuts must be reinstalled.
