Other controls
46 Controls
8 Control panel
1
Retarder in brake pedal
8
Unassigned
2
Exhaust braking in accelerator pedal
9
Wiper and washer, rear window
(optional equipment)
3
Gear-shift inhibitor
10
Unassigned
4
The gear selector
11
Load and dump brake
5
Longitudinal differential lock and 6-wheel drive
(if the machine is equipped with ATC, see page 49)
12
Tipping control
6
Transverse differential lock
(if the machine is equipped with ATC, see page 49)
13
Lock-out control for tipping control
7
Unassigned
14
Parking brake
1
2
3
13
14
12
11
5
6
7
4
1048525
P
l
