Specifications
178 Electrical system, specifications
3 5 A Position monitor seatbelt,
position monitor seat cushion,
position monitor shut-off valve
hydraulic oil tank, pressure
monitor return oil filter
hydraulic oil, pressure monitor
return oil filter cooling fan oil,
socket service display unit
24 15 A T-ECU, feed 28 VDC
4 10 A Switch parking brake 25 15 A V-ECU, feed 28 VDC
5 15 A Interior lighting, interior lighting
(left/right rear), interior lighting
(right front), position monitor
door
26 15 A D-ECU, feed 28 VDC
6 15 A Rotating beacon 27 15 A Switch headlights
Main fuse for guide lights, running
lights, high and low beams for
fuses 13–15, 35, 36, and 38
7 5 A Direction indicators, flashing
hazard lights
28 15 A Headlight flasher
8 15 A Fan climate control system
(AC), relay climate control
system (AC), monitor
refrigerant pressure, monitor
refrigerant temperature
Solenoid valve control
compressor climate control
system (AC)
29 5 A Switch working lights front/rear,
relay working light front/rear,
working lights front/rear left/right
Unassigned (belongs to relay
socket no. 7)
9 10 A Switch transverse diff. lock
(front axle), longitudinal diff.
lock/6
×6, all diff. locks/6×6
Position monitor longitudinal
diff. lock
30 15 A Switch electrically heated rear-view
mirrors
Heating coil rear-view mirror left/
right lower/upper
Switch seat cushion heater, heating
coil seat cushion heat, switch and
control light turn-around wheels
10 5 A Unassigned 31 15 A Cigarette lighter
11 5 A Unassigned 32 10 A Voltage converter, switch flashing
hazard lights, flasher relay,
tachograph
12 15 A E-ECU, Feed 28VDC E-ECU
(including function engine stop)
33 25 A Power outlet 28 VDC
13 5 A Low beam, right 34 15 A
Switch windshield wiper, relay
interval wiper, motor windshield
wiper, switch windshield washer,
relay windshield washer, motor
windshield washer, switch horn, horn
14 5 A Low beam, left 35 5 A Running lights left/right front, front
fender and rear
Control guide lights switches
Guide light switches
15 5 A High beam, right 36 5 A Running lights, instrument lighting
16 10 A Buzzer, central warning 37 15 A Working lights front
17 15 A Unassigned 38 5 A High beam left, D-ECU signal for
activating high beam
18 15 A Starter motor, control voltage 39 15 A Working lights rear
Marking Rated
current
Description (blade fuse) Marking Rated
current
Description (blade fuse)
