Specifications
Electrical system, specifications 179
Other fuses
19 15 A Back-up (reversing) lights,
back-up warning, back-up
camera
40 10 A Brake lights
20 5 A Voltage converter 41 5 A Ground tachograph
21 5 A Back-up (reversing) camera 42 20 A Unassigned
Marking Rated
current
Description (fuse rail) Marking Rated
current
Description (blade fuse)
FC1 50 A Main fuse FH2 10 A Delayed stop
FC2 150 A Heating coil preheating FH3 5 A Relay preheating induction air
FC3 40 A Motor hood pump FH4 5 A Exhaust gas recirculation (EGR),
exhaust brake (EPG)
Fuse for rear window wiper/washer, see page 94. FH5 5 A Load and dump brake
Marking Rated
current
Description (blade fuse) Marking Rated
current
Description (blade fuse)
1014832
FC1FC3FC2
1048318
FH5
In fuse box on battery bracket over
washer reservoir
Left side in cab
