Service and maintenance
138 Power transmission
Transmission, replacing breather filter
Replace the breather filter every 2000 hours.
The filter is of the disposable type, i.e. it cannot be cleaned
but must be replaced.
1 Loosen the clamp and remove filter (A).
2 Move the clamp over to the new filter and install it.
Suction strainer in power take-off, cleaning
The suction strainer shall be cleaned every 2000 hours.
Suction strainer (C) is located on the front of the power take-off on
the flywheel housing.
1 Lower the guard plate and leave it suspended by the chain.
2 Disconnect the hose (A).
NOTE! Approx. 2 dl of oil will run out.
3 Remove the connection (B).
4 Remove and clean the strainer (C).
5 Reinstall the strainer and the connection.
6 Reinstall the hose.
7 Raise the guard plate.
WARNING!
Hot oil can cause severe burns on unprotected skin.
A
4
1
A
A Breather filter
AHose
B Connection
C Suction strainer
A
C
B
