Volvo A25E - Page 192

Specifications
192 Dimensional drawing, A25E
*) Applies to machines with body height extension for light material
Dimensions apply to unloaded machine with tyres 23.5 R25
Dimension
Overall length A 10220 mm (33 ft 6.4 in)
Overall length* A* 10828 mm (35 ft 6.3 in)
Overall length, tractor unit A
1
4954 mm (16 ft 3.0 in)
Overall length, trailer unit A
2
5764 mm (18 ft 10.9 in)
Dump body length, standard body B 5152 mm (16 ft 10.8 in)
Overall height across exhaust pipe C 3453 mm (11 ft 3.9 in)
Height to roof of cab C
1
3318 mm (10 ft 10.6 in)
Width across cab C
2
1768 mm (5 ft 4.3 in)
Overall height over spill guard, lowered dump body C
3
3760 mm (12 ft 4.0 in)
Overall height over spill guard, lowered dump body* C
3
3590 mm (11 ft 9.3 in)
Overhang, towing eyes D 2604 mm (8 ft 6.5 in)
Distance, front axle – steering centre E 1210 mm (3 ft 11.6 in)
Wheel base, drive axles F 4175 mm (13 ft 4.4 in)
Wheel base, bogie axles G 1670 mm (5 ft 5.7 in)
Overhang, rear H 1610 mm (5 ft 3.4 in)
Overhang, frame I 608 mm (1 ft 11.9 in)
Loading height J 2778 mm (9 ft 1.4 in)
Loading height* J* 3484 mm (11 ft 5.2 in)
Height to dump body K 2102 mm (6 ft 10.8 in)
Free tipping height L 677 mm (2 ft 2.7 in)
Overall height, tipped dump body M 6559 mm (21 ft 6.2 in)
Overall height, tipped dump body* M* 6587 mm (21 ft 7.3 in)
Outer turning radius N 8105 mm (26 ft 7.1 in)
Inner turning radius N
1
4079 mm (13 ft 4.6 in)
Outside width, dump body O 2700 mm (8 ft 10.3 in)
Outside width, dump body* O* 2874 mm (9 ft 5.1 in)
Inside width, dump body P 2490 mm (8 ft 2.0 in)
Lowest ground clearance, trailer unit R 512 mm (1 ft 8.2 in)
Ground clearance axle, trailer unit R
1
634 mm (2 ft 1.0 in)
Max. height, upper body plate dump body U 3257 mm (10 ft 8.2 in)
Track width, trailer unit V 2258 mm (7 ft 4.9 in)
Overall width, trailer unit W 2859 mm (9 ft 4.6 in)
Lowest ground clearance, tractor unit X 456 mm (1 ft 6.0 in)
Ground clearance axle, tractor unit X
1
581 mm (1 ft 10.9 in)
Ground clearance, hitch X
2
659 mm (2 ft 1.9 in)
Track width, tractor unit Y 2258 mm (7 ft 4.9 in)
Overall width, tractor unit Z 2859 mm (9 ft 4.6 in)
Approach angle a
1
23.5°
Tipping angle a
2
74°
Max. steering lock a
3
45°
