Specifications
Dimensional drawing, Hauler chassis 199
Hauler chassis A25E 4x4
Dimensions apply with tyres 23.5 R25
A 7941 mm (26 ft 0.6 in)
B 2800 mm (9 ft 2.2 in)
B1 500 mm (1 ft 7.7 in)
B2 2720 mm (8 ft 11.1 in)
B3 1639 mm (5 ft 4.5 in)
C 3470 mm (11 ft 4.6 in)
C1 3332 mm (10 ft 11.2 in)
C2 1768 mm (5 ft 9.6 in)
D 2766 mm (9 ft 0.9 in)
E 1210 mm (3 ft 11.6 in)
F 4254 mm (13 ft 11.5 in)
H 585 mm (1 ft 11 in)
I 921 mm (3 ft 0.3 in)
J 496 mm (1 ft 7.5 in)
K 1425 mm (4 ft 8.1 in)
L 995 mm (3 ft 3.2 in)
N 7092 mm (23 ft 3.2 in)
N1 3197 mm (10 ft 5.9 in)
R 637 mm (2 ft 1.1 in)
R1 664 mm (2 ft 2.1 in)
V 2374 mm (7 ft 9.5 in)
W 3117 mm (10 ft 2.8 in)
X 461 mm (1 ft 6.1 in)
X1 585 mm (1 ft 11 in)
X2 585 mm (1 ft 0.6 in)
Y 2258 mm (26 ft 0.6 in)
Z 2859 mm (26 ft 0.6 in)
a1 23.5°
a3 45°
Service weight Total weight
Front axle 11800 kg
(26010 lb)
15650 kg
(34500 lb)
Rear axle 3705 kg
(8168 lb)
27820 kg
(61330 lb)
Total 15505 kg
(34180 lb)
43470 kg
(95830 lb)
Load capacity incl.
superstructure
27965 kg
(61650 lb)
–
