Specifications
Dimensional drawing, Hauler chassis 201
Standard Hauler chassis
* free zone, superstructure not permitted within the area, applies to max. width.
A25E
Dimensions apply with tyres 23.5 R25
A30E
Dimensions apply with tyres 750/65 R25
A 9410 mm (30 ft 10.4 in) 9410 mm (30 ft 10.4 in)
B 4520 mm (14 ft 10 in) 4520 mm (14 ft 10 in)
B1* 500 mm (1 ft 7.7 in) 500 mm (1 ft 7.7 in)
B2 4420 mm (14 ft 6 in) 4420 mm (14 ft 6 in)
B3 2554 mm (8 ft 4.55 in) 2517 mm (8 ft 3.1 in)
C 3428 mm (11 ft 3in) 3428 mm (11 ft 3in)
C1 3318 mm (10 ft 10.6 in) 3318 mm (10 ft 10.6 in)
C2 1768 mm (5 ft 4.3 in) 1768 mm (5 ft 4.3 in)
D 2764 mm (9 ft 0.82 in) 2764 mm (9 ft 0.82 in)
E 1210 mm (3 ft 11.6 in) 1210 mm (3 ft 11.6 in)
F 4175 mm (13 ft 4.4 in) 4175 mm (13 ft 4.4 in)
G 1670 mm (5 ft 5.7 in) 1670 mm (5 ft 5.7 in)
H 422 mm (1 ft 4.62 in) 459 mm (1 ft 6.1 in)
I 608 mm (1 ft 11.9 in) 608 mm (1 ft 11.9 in)
J 1444 mm (4 ft 8.86 in) 1444 mm (4 ft 8.86 in)
K 1400 mm (4 ft 7.12 in) 1400 mm (4 ft 7.12 in)
L 940 mm (3 ft 1.01 in) 1005 mm (3 ft 3.56 in)
M 365 mm (1 ft 2.38 in) 380 mm (1 ft 2.96 in)
M1 720 mm (2 ft 4.34 in) 615 mm (2 ft 0.22 in)
N 8105 mm (26 ft 7.1 in) 8105 mm (26 ft 7.1 in)
N1 4079 mm (13 ft 4.56 in) 4037 mm (13 ft 2.88 in)
R 512 mm (1 ft 8.16 in) 513 mm (1 ft 8.2 in)
R1 634 mm (2 ft 0.96 in) 635 mm (2 ft 1.0 in)
V 2258 mm (7 ft 4.87 in) 2216 mm (7 ft 3.24 in)
W 2859 mm (9 ft 4.56 in) 2941 mm (9 ft 7.8 in)
X 456 mm (1 ft 6.0 in) 456 mm (1 ft 6.0 in)
X1 581 mm (1 ft 10.87 in) 582 mm (1 ft 10.9 in)
X2 659 mm (2 ft 1.9 in) 659 mm (2 ft 1.9 in)
Y 2258 mm (7 ft 4.87 in) 2216 mm (7 ft 3.2 in)
Z 2859 mm (9 ft 4.56 in) 2941 mm (9 ft 7.8 in)
a1 23.5° 23.5°
a3 45° 45°
A25E A30E
Service weight Total weight Service weight Total weight
Front axle 11798 kg
(26010 lb)
14140 kg
(31170 lb)
12028 kg
(26520 lb)
14990 kg
(33050 lb)
Combined rear axles 5985 kg
(13190 lb)
31420 kg
(69270 lb)
6683 kg
(14730 lb)
36070 kg
(79520 lb)
Total 17783 kg
(39200 lb)
45560 kg
(100400 lb)
18711 kg
(41250 lb)
51060 kg
(112600 lb)
Load capacity incl.
superstructure
27777 kg
(61240 lb)
– 32349 kg
(71320 lb)
–
