Volvo A25E - Page 203

Specifications
Dimensional drawing, Hauler chassis 203
Standard Hauler chassis with 1200 mm frame extension
* free zone, superstructure not permitted within the area, applies to max. width.
A25E
Dimensions apply with tyres 23.5 R25
A30E
Dimensions apply with tyres 750/65 R25
A 10620 mm (34 ft 10.1 in) 10620 mm (34 ft 10.1 in)
B 5720 mm (17 ft 3.5 in) 5720 mm (17 ft 3.5 in)
B1* 500 mm (1 ft 7.7 in) 500 mm (1 ft 7.7 in)
B2 5620 mm (18 ft 5.3 in) 5620 mm (18 ft 5.3 in)
B3 3692 mm (12 ft 1.32 in) 3713 mm (12 ft 2.2 in)
C 3428 mm (11 ft 3 in) 3428 mm (11 ft 3 in)
C1 3318 mm (10 ft 10.7 in) 3318 mm (10 ft 10.7 in)
C2 1768 mm (5 ft 9.61 in) 1768 mm (5 ft 9.61 in)
D 2764 mm (9 ft 0.82 in) 2764 mm (9 ft 0.82 in)
E 1210 mm (3 ft 11.64 in) 1210 mm (3 ft 11.64 in)
F 5375 mm (17 ft 7.6 in) 5375 mm (17 ft 7.6 in)
G 1670 mm (5 ft 5.75 in) 1670 mm (5 ft 5.75 in)
H 484 mm (1 ft 7.1 in) 539 mm (1 ft 9.22 in)
I 608 mm (1 ft 11.94 in) 608 mm (1 ft 11.94 in)
J 1444 mm (4 ft 8.86 in) 1444 mm (4 ft 8.86 in)
K 1400 mm (4 ft 7.12 in) 1400 mm (4 ft 7.12 in)
L 940 mm (3 ft 1.01 in) 1005 mm (3 ft 3.56 in)
M 365 mm (1 ft 2.38 in) 380 mm (1 ft 2.96 in)
M1 720 mm (2 ft 4.34 in) 615 mm (2 ft 0.22 in)
N 9670 mm (31 ft 8.76 in) 9711 mm (31 ft 10.32 in)
N1 5270 mm (17 ft 3.48 in) 5229 mm (17 ft 1.92 in)
R 512 mm (1 ft 8.16 in) 513 mm (1 ft 8.2 in)
R1 634 mm (2 ft 0.96 in) 635 mm (2 ft 1.0 in)
V 2258 mm (7 ft 4.87 in) 2216 mm (7 ft 3.24 in)
W 2859 mm (9 ft 4.56 in) 2941 mm (9 ft 7.8 in)
X 456 mm (1 ft 6.0 in) 456 mm (1 ft 6.0 in)
X1 581 mm (1 ft 10.87 in) 582 mm (1 ft 10.9 in)
X2 659 mm (2 ft 1.9 in) 659 mm (2 ft 1.9 in)
Y 2258 mm (7 ft 4.87 in) 2216 mm (7 ft 3.2 in)
Z 2859 mm (9 ft 4.56 in) 2941 mm (9 ft 7.8 in)
a1 23.5° 23.5°
a3 45° 45°
A25E A30E
Service weight Total weight Service weight Total weight
Front axle 12020 kg
(26500 lb)
14140 kg
(31170 lb)
12689 kg
(27970 lb)
14990 kg
(33050 lb)
Combined rear axles 6319 kg
(13930 lb)
31420 kg
(69270 lb)
6569 kg
(14480 lb)
36070 kg
(79520 lb)
Total 18339 kg
(40430 lb)
45560 kg
(100200 lb)
19267 kg
(42480 lb)
51060 kg
(112600 lb)
Load capacity incl.
superstructure
27221 kg
(60010 lb)
– 31793 kg
(70090 lb)
–
