Specifications
Dimensional drawing, Hauler chassis 205
Standard Hauler chassis with 1700 mm frame extension
* free zone, superstructure not permitted within the area, applies to max. width.
A25E
Dimensions apply with tyres 23.5 R25
A30E
Dimensions apply with tyres 750/65 R25
A 11120 mm (36 ft 5.76 in) 11120 mm (36 ft 5.76 in)
B 6220 mm (20 ft 4.92 in) 6220 mm (20 ft 4.92 in)
B1* 500 mm (1 ft 7.7 in) 500 mm (1 ft 7.7 in)
B2 6120 mm (20 ft 0.96 in) 6120 mm (20 ft 0.96 in)
B3 4169 mm (13 ft 8.16 in) 4105 mm (13 ft 5.64 in)
C 3428 mm (11 ft 3 in) 3428 mm (11 ft 3 in)
C1 3318 mm (10 ft 10.68 in) 3318 mm (10 ft 10.68 in)
C2 1768 mm (5 ft 9.61 in) 1768 mm (5 ft 9.61 in)
D 2764 mm (9 ft 0.82 in) 2764 mm (9 ft 0.82 in)
E 1210 mm (3 ft 11.6 in) 1210 mm (3 ft 11.6 in)
F 5875 mm (19 ft 3.24 in) 5875 mm (19 ft 3.24 in)
G 1670 mm (5 ft 5.75 in) 1670 mm (5 ft 5.75 in)
H 507 mm (1 ft 7.96 in) 571 mm (1 ft 10.48 in)
I 608 mm (1 ft 11.94 in) 608 mm (1 ft 11.94 in)
J 1444 mm (4 ft 8.86 in) 1444 mm (4 ft 8.86 in)
K 1400 mm (4 ft 7.12 in) 1400 mm (4 ft 7.12 in)
L 940 mm (3 ft 1.01 in) 1005 mm (3 ft 3.56 in)
M 365 mm (1 ft 2.38 in) 380 mm (1 ft 2.96 in)
M1 720 mm (2 ft 4.34 in) 615 mm (2 ft 0.22 in)
N 10360 mm (33 ft 11.9 in) 10401 mm (34 ft 1.44 in)
N1 5770 mm (18 ft 11.16 in) 5729 mm (18 ft 9.6 in)
R 512 mm (1 ft 8.16 in) 513 mm (1 ft 8.2 in)
R1 634 mm (2 ft 0.96 in) 635 mm (2 ft 1.0 in)
V 2258 mm (7 ft 4.87 in) 2216 mm (7 ft 3.24 in)
W 2859 mm (9 ft 4.56 in) 2941 mm (9 ft 7.8 in)
X 456 mm (1 ft 6.0 in) 456 mm (1 ft 6.0 in)
X1 581 mm (1 ft 10.87 in) 582 mm (1 ft 10.9 in)
X2 659 mm (2 ft 1.9 in) 659 mm (2 ft 1.9 in)
Y 2258 mm (7 ft 4.87 in) 2216 mm (7 ft 3.2 in)
Z 2859 mm (9 ft 4.56 in) 2941 mm (9 ft 7.8 in)
a1 23.5° 23.5°
a3 45° 45°
A25E A30E
Service weight Total weight Service weight Total weight
Front axle 12096 kg
(26670 lb)
14140 kg
(31170 lb)
12914 kg
(28470 lb)
14990 kg
(33050 lb)
Combined rear axles 6412 kg
(14140 lb)
31420 kg
(69270 lb)
6522 kg
(14380 lb)
36070 kg
(79520 lb)
Total 18508 kg
(40800 lb)
45560 kg
(100400 lb)
19436 kg
(42850 lb)
51060 kg
(112600 lb)
Load capacity incl.
superstructure
27052 kg
(59640 lb)
– 31624 kg
(69720 lb)
–
