Chapter 1 Introduction
8
Model
Motor
power
(kW)
Rated input
current (A)
External dimensions
Installation
dimensions
(mm)
wide
height
depth
V810-6T4000G/4500P
400
430
Wall
mounting
: 1040.
Switchbo
ard: 1515
680
400
Wall mounting:
1016*520*011
Switchboard:
550*300*013
V810-6T4500G/5000P
450
480
V810-6T5000G/5600P
500
540
V810-6T5600G/6300P
560
600
1800
650
920
550*800*017
V810-6T6300G/7100P
630
680
V810-6T7100G/8000P
710
750
1800
750
920
650*800*017
V810-6T8000G/9000P
800
860
V810-6T9000G/10000P
900
950
1800
900
920
800*800*017
V810-6T10000G
1000
1080
1.3 Drawing of the external dimensions of the inverter
