VYBO Electric Vector V810 - Group P3: Vector Control Parameters

Chapter 4: Description of functions (abbreviated)
42
Group P3: Vector control parameters
P3.00
Linear constant 1
1-100
30
☆
P3.01
Integration constant 1
0.01 s to 10.00s
0.50s
☆
P3.02
Frequency
of switching 1
0.00-P3.05
5.00Hz
☆
P3.03
Linear constant 2
1-100
20
☆
P3.04
Integration constant 2
0.01 s to 10.00s
1.00s
☆
P3.05
Frequency
of switching 2
P3.02 – maximum output frequency
10.00Hz
☆
P3.06
Vector control slip
50% to 200%
100%
☆
P3.07
Time constant of filter
of the loop speed
0.000s-0.100s
0.000s
☆
P3.08
Over excitation gain
0-200
64
☆
P3.09
Torque upper limit
source in speed control
mode
0: Set via P3.10
1: FIV
2: FIC
3: Reserved
4: Impulse setting (X5)
5: Communication setting via RS 485
6: MIN(FIV,FIC)
7: MAX(FIV,FIC)
0
☆
P3.10
Digital setting of torque
upper limit in speed
control mode
0.0% to 200.0%
150.0%
☆
