VYBO Electric Vector V810 - Group P4: V;F Control Parameters

Chapter 4: Description of functions (abbreviated)
44
Group P4: V/F Control Parameters
Function
code
Parameter name
Setting range
Default
setting
Property
P4.00
Setting the V/F curve
0: Linear V/F curve
1 : Multipoint V/F curve
2: Square V/F curve
3: 1.2-fold V/F curve
4: 1.4-fold V/F curve
6: 1.6-fold V/F curve
8: 1.8-fold V/F curve
9: Reserved
10: V/F complete separation
11: V/F half separation
0
★
P4.01
Increase of torque
0.0%: (Auto increase)
0.1% to 30.0%
By the
model
☆
P4.02
Torque limitation
0.00 Hz – maximum output frequency
50.00Hz
★
P4.03
Multi-point V/F
frequency curve 1
0.00 Hz - P4.05
0.00Hz
★
P4.04
Multipoint V/F voltage
curve 1
0.0% to 100.0%
0.0%
★
P4.05
Multi-point V/F
frequency curve 2 (F2)
P4.03 to P4.07
0.00Hz
★
P4.06
Multipoint V/F voltage
curve 2 (V2)
0.0% to 100.0%
0.0%
★
P4.07
Multi-point V/F
frequency curve 3 (F3)
P4.05 - rated motor frequency (P2.04)
0.00Hz
★
P4.08
Multipoint V/F voltage
curve 3 (V3)
0.0% to 100.0%
0.0%
★
