VYBO Electric Vector V810 - Group PA: PID Process Control Functions

Chapter 4: Description of functions (abbreviated)
66
Group PA: PID process control functions
Function
code
Parameter name
Setting range
Default
setting
Property
PA.00
Setting of source the
required value of PID
0:PA.01
1:FIV
2:FIC
3:Reserved
4: PULSE setting (X5)
5: Communication settings
6: Multiple meaning
0
☆
PA.01
Digital setting of PID
0.0% - 100.0%
50.0%
☆
PA.02
Setting of source the
feedback of PID
0:FIV
1:FIC
2:Reserved
3:FIV-FIC
4: PULSE setting (X5)
5: Communication settings
6:FIV+FIC
7:MAX(|FIV|, |FIC|)
8:MIN(|FIV|, |FIC|)
0
☆
PA.03
Direction of action the
PID
0: Action forward
1: Action backward (reverse)
0
☆
PA.04
Setting range of PID
feedback
0 - 65535
1000
☆
PA.05
Linear constant Kp1
0.0 - 100.0
20.0
☆
PA.06
Integration constant Ti1
0.01 s - 10.00s
2.00s
☆
PA.07
Derivation constant Td1
0.000 - 10.000s
0.000s
☆
PA.08
Disconnection frequency
PID of reverse rotation
0.0 – maximum frequency
2.00Hz
☆
PA.09
Limit of PID deviation
0.0% - 100.0%
0.0%
☆
PA.10
PID differential limit
0.00% - 100.00%
0.10%
☆
