1.0 Technical parameters
V/F scalar control
SVC vector control with open circuit
CLVC vector control with close circuit
SVC, CLVC vector control: 0 - 300 Hz
V/F scalar control: 0 - 3200 Hz
1-16 kHz
The carrier frequency is automatically adjusted based on the load characteristic.
Input frequency
resolution
Digital setting 0.01 Hz
Analogy setting: maximum frequency x 0.025%
G type: 0.5 Hz/150% (SFVC)
G type: 0.5 Hz / 180% (CLVC)
P type: 0.5 Hz/100%
1:100 (SVC)
1:1000 (CLVC)
± 0.50 % (SVC)
± 0.02 % (CLVC)
G type: 60s for 150% rated current, 3s for 180% rated current
P type: 60s for 120% rated current, 3s for 150% rated current
Auto-boost or user manual boost 0.1% až 30.0%
Linear V/F curve
Multi-point V/F curve
N-voltage V/F curve (multiple of 1.2-voltage, 1.4- voltage, 1.6- voltage, 1.8-
voltage, modified)
Two types: complete separation; half separation
Linear curve
The ramp of S-curve type
Four sets of acceleration / deceleration in ranges of 0.0-6500.0 sec
8 digital inputs, binary inputs ON / OFF, 1 terminal X5 can support high speed pulse
input. All terminals have optional PNP or NPN.
2 analogue inputs, of which one FIV supports -10 V / +10 V; or a 0-10 V input and
the second FIC supports a 0-10V or 0-20mA (4-20 mA) input.
1 programmable open collector output: provides 1 output terminal (output of
open collector or high speed pulse output)
2 relay outputs, 2 analogue outputs: FOV and FOC with optional 0-20 mA (4-20
mA) or 0-10 V output
