The inverter is equipped with a port for PG cards (for encoder), or PG cards for use
with a resolver, etc..
Braking frequency: 0.00 Hz to maximum frequency
Braking time: 0.0-36.0 s
Braking current: 0.0% -100.0%
Models up to 18.5 kW have a built-in brake unit as standard.
Control in JOG mode
(stepping)
JOG frequency range: 0.00-50.00 Hz
JOG acceleration / deceleration time: 0.0-6500.0 s
Implement multiple
preset speeds PLC
Implemented up to 16 speeds using a simple PLC function or combinations of end
states X.
Input for PTC motor thermal protection.
Facilitates a process-controlled closed-loop control system.
Automatic voltage
control (AVR)
When changing the supply voltage, it can automatically maintain a constant output
voltage.
Overvoltage and
overcurrent control
Current and voltage are automatically limited during operation to prevent
frequent tripping due to overvoltage and over current.
Torque limitation and
control
It can automatically limit the torque and prevent frequent over current during run.
"Emergency stop" system: In emergency situations, the inverter stops immediately
after activating EMS STOP.
Speed limitation of
current
It helps to prevent frequent errors due to over current of the AC motor
AC motor control is realized by high power vector current control technology.
Time range: 0.0-6500.0 minutes
Channel of trigger
commands
According to the panel, control terminals, the serial communication port can be
switched in many ways.
10 types of frequencies, given by digital analogue voltage, analogue current, pulse,
serial port, X8, PID, can be switched in many ways.
Auxiliary source of
frequency
10 types of frequencies, it is easy to realize micro setup, frequency synthesizer.
Lock keys and select
functions
It can block the buttons partially or completely and define the range of functions
of some buttons to prevent malfunctions.
