VYBO Electric Vector V810 - Group P6: Output Terminals

Chapter 4: Description of functions (abbreviated)
50
P5.35
X1 delay time
0.0s - 3600.0s
0.0s
★
P5.36
X2 delay time
0.0s -~ 3600.0s
0.0s
★
P5.37
X3 delay time
0.0s - 3600.0s
0.0s
★
P5.38
Selecting the allowed X-
mode 1
0: High level
1: Low level
_ _ _ _ X : X1 allowed mode
_ _ _ X _ : X2
_ _ X _ _ : X3
_ X _ _ _ : X4
X _ _ _ _ : X5
00000
★
P5.39
Selecting the allowed X-
mode 2
0: High level
1: Low level
_ _ _ _ X : X6 allowed mode
_ _ _ X _ : X7
_ _ X _ _ : X8
_ X _ _ _ : X9
X _ _ _ _ : X10
00000
★
Group P6: Output terminals
Function
code
Parameter name
Setting range
Default
setting
Property
P6.00
YO terminal output
mode
0: Pulse output signal (YO-P)
1: On / Off output signal (YO-R)
0
☆
