Chapter 4: Description of functions (abbreviated)
51
P6.01
P6.02
P6.03
P6.04
P6.05
Function YO-R
(0-40)
Relay output function YA-
YB-YC
(0-40)
Relay output function
RA-RB-RC
(0 – 40)
Reserved
Reserved
0: No output
1: Inverter in RUN mode
2: Output error (stop)
3: Detection of the FDT1 frequency level
4: Frequency achieved
5: Run at zero speed
6: Pre-warning of overloading the motor
7: Pre-warning of overloading the inverter
8: Set counter value reached
9: Counter set value reached
10: Length reached
11: The entire PLC cycle completed
12: The cumulative operating time reached
13: Limited frequency
14: Limited torque
15: The inverter is ready to RUN
16: FIV > FIC
17: The upper frequency limit reached
18: The lower frequency limit reached
19: Under voltage
20: Communication setting
21: Reserved
22: Reserved
23: Run at zero speed
24: Total time under voltage reached
25: Detection of the FDT2 frequency level
26: Frequency reached 1
27: Frequency reached 2
28: Current reached 1
29: Current reached 2
30: Time reached
31: FIV entry limit exceeded
32: Zero load
33: Reverse RUN
34: Zero current
35: Module temperature reached
36: Exceeded current limit
37: Frequency lower limit reached
38: Alarm
39: Reserved
40: Actual running time reached
0
2
0
0
0
☆
