Chapter 4: Description of functions (abbreviated)
76
C5.05
Detection of current
compensation
0-100
5
☆
C5.06
Setting the under voltage
60.0% - 140.0%
100.0%
☆
C5.07
Selection SFVC optimization
mode
0: No optimization
1: Optimization mode 1
2: Optimization mode 2
1
☆
C5.08
Dead band time adjustment
100 % to 200 %
150 %
☆
Group C6: FI curve setting (FI is FIV or FIC)
C6.00
FI curve 4 minimum
-10.00V - C6.02
0.00V
☆
C6.01
Corresponding FI 4 curve
setting minimum
-100.0% - +100.0%
0.0%
☆
C6.02
FI curve 4 inflexia 1
C6.00 - C6.04
3.00V
☆
C6.03
Corresponding FI curve 4
setting inflexia 1
-100.0% - +100.0%
30.0%
☆
C6.04
FI curve 4 inflexia 2
C6.02 - C6.06
6.00V
☆
C6.05
Corresponding FI curve 4
setting inflexia 2
-100.0% - +100.0%
60.0%
☆
C6.06
FI curve 4 maximum
C6.06-+10.00V
10.00V
☆
C6.07
Corresponding FI curve 5
setting max.
-100.0% - +100.0%
100.0%
☆
C6.08
FI curve 5 minimum
-10.00V - C6.10
0.00V
☆
C6.09
Corresponding FI curve 5
setting minimum
-100.0% - +100.0%
-100.%
☆
