VYBO Electric Vector V810 - Group P2: Motor Parameters

Chapter 4: Description of functions (abbreviated)
39
P1.10
STOP mode
0: Deceleration to stop according to the curve
1: Idle deceleration
0
☆
P1.11
Initial frequency of
stop DC braking
0.00 Hz – maximum frequency
0.00Hz
☆
P1.12
Waiting time of
stop DC braking
0.0s to 100.0s
0.0s
☆
P1.13
Braking DC current
at stop
0% to 100%
0%
☆
P1.14
DC braking time
0.0s to 100.0s
0.0s
☆
P1.15
Braking rate
0 – 100 %
100 %
☆
Group P2: Motor parameters
P2.00
Motor type
selection
0: Common asynchronous motor
1: Variable frequency asynchronous motor
2: Synchronous motor with permanent magnets
0
★
P2.01
Rated motor
power
0.1kW to 1000.0kW
By the
model
★
P2.02
Rated motor
voltage
1V to 2000V
By the
model
★
P2.03
Rated motor
current
0.01 A to 6553.5A
By the
model
★
P2.04
Rated motor
frequency
0.01 Hz – Maximum frequency
By the
model
★
P2.05
Rated motor speed
1 rpm to 65535 rpm
By the
model
★
P2.06
Stator resistance
(asynchronous
motor)
0.01- 65.535 Ω
By the
model
★
