Chapter 1 Introduction
10
Model
External dimensions
Installation
dimensions
A*B*Ø d
V mm
W
H
H1
D
Installation
Note
V810-2S0004
125
170
—
140
117*160*Ø5
Wall mounting
Of plastic
V810-2S0007
V810-2S0015
V810-2S0022
V810-2S0030
120
225
—
143
105*208*Ø5
Partly of
plastic
V810-4T0004
125
170
—
140
117*160*Ø5
Of plastic
V810-4T0007
V810-4T0015
V810-4T0022
V810-4T0040G/0055P
120
225
—
143
105*208*Ø5
Wall mounting
Partly of
plastic
V810-4T0055G/0075P
185
260
—
170
168*248*Ø6.5
Of plastic
V810-4T0075G/0110P
V810-4T0110G/0150P
210
330
—
190
195*310*Ø6.5
Partly of
plastic
V810-4T0150G/0185P
V810-4T0185G/0220P
277
410
—
189
262*390*Ø6.5
Metal cabinet
V810-4T0220G/0300P
V810-4T0300G/0370P
V810-4T0370G
V810-4T0370G/0450P
300
430
455
212
200*433*Ø9
V810-0450G/0550P
300
535
560
236
200*538*Ø9
V810-4T0550G
V810-4T0750P
V810-4T0750G/0900P
338
546
576
256.5
270*560*Ø9
New
V810-4T0900G/1100P
338
550
580
300
270*564*Ø9
V810-4T1100G/1320P
