Chapter 2 Wiring of V 810
17
Terminal
Description
X1-X8
ON-OFF signal input, optical PLC and COM connection. Input voltage
range: 9-30V. Input impedance: 3.3kΩ
X5
High-speed pulse or ON-OFF input signal, optical PLC and COM
connection. Pulse input frequency range: 0 to 100kHz. Input voltage
range: 9-30 V. Input impedance: 100 kΩ.
PLC
External power supply. The +24 V terminal is connected to the PLC
terminal as the default setting. If the user needs external power,
disconnect the +24 V terminal from the PLC terminal (go to PNP method).
Terminal
Description
+24V
It provides an output voltage of +24 V. The maximum output current is
150 mA.
FIV
Analogue input -10V / +10 V. Input impedance: 20 kΩ
FIC
Analogue input 0-10 V / 0-20mA, switches via J3. Input impedance: 10kΩ
(for input voltage) / 250 Ω (for input current)
GND
Common ground terminal of analogue signal and + 10V. The GND
terminal must be isolated from COM.
+10V
Power supply + 10V for inverter. High speed pulse output terminal. The
corresponding common ground terminal is COM.
YO
Output frequency range: 0 to 100 kHz.
COM
Common (zero potential) terminal for digital signal and +24 V (or external
power supply).
FOV/FOC
It provides a voltage or current output that can be switched using J4 and
J1. Output range: 0 - 10V / 0 - 20mA (4-20 mA).
RA/RB/RC
Relay output: RC - common, RB = NC, RA = NO. Contact rating: AC 250V /
3A; DC 30V / 1 A.
YA/YB/YC
Relay output: YC - common, YB = NC, YA = NO. Contact rating: AC 250V /
3A; DC 30V / 1 A.
RS+ / RS-
RS485 communication port. RS485 differential signal, +, -.
