0: No function
1: RUN forward (FWD)
2: Reverse RUN (REV)
3: Three-wire control
4: RUN forward JOG (FJOG)
5: Reverse RUN (RJOG)
6: Terminal UP
7: Terminal DOWN
8: Gradual stop
9: RESET of the fault (RESET)
10: Pause during RUN
11: Normally open (NO) input of an external
error
12: Fixed speed 1
13: Fixed speed 2
14: Fixed speed 3
15: Fixed speed 4
16: Terminal 1 for selecting acceleration /
deceleration time
17: Terminal 2 for selecting acceleration /
deceleration time
18: Switching frequency source X/Y
19: Reset via UP and DOWN (terminal, control
panel)
20: Command source switchover terminal
21: Acceleration / deceleration disabled
22: Pause of PID
23: Recovering the PLC status
Value: Function
24: Swing break
25: Counter input
26: Reset the counter
27: Length count input
28: Resetting the length
29: Torque control disabled
30: 30: Pulse input (S3 only)
31: Reserved
32: Immediate DC braking
33: Normally closed (NC) external error input
(via X suitable for PTC)
34: Changing the frequency is disabled
35: Reverse direction of PID
36: Terminal for external STOP 1
