SmartBoard
8
Annex
51
Message Explanation
089 Proximity switch
090 Freely configurable function 8
091 Freely configurable function 7
092 Freely configurable function 6
093 Freely configurable function 5
094 Freely configurable function 4
095 Freely configurable function 3
096 Freely configurable function 2
097 Freely configurable function 1
100 GIO-Freely configurable analogue function
101 GIO-Freely configurable digital function
102 Slot GIO 5
103 Slot GIO 4
104 Slot GIO 3
105 Slot GIO 2
106 Slot GIO 1
107 Slot GIO 6
108 Slot GIO 7
109 ABS sensor/ Memory bit
110 Slot Subsystems
111 Button Relaxation function
112 Button Lifting axle forced lowering
113 SmartBoard
114 Diagnostics Power supply
115 Telematics
116 IVTM
117 ECAS Remote Control Unit / Box
118 Axle load sensor external (axle c, d)
119 Axle load sensor external (axle e, f)
120 Distance sensor axle load (axle c, d)
121 Distance sensor axle load (axle e, f)
122 freely programmable function 3
123 freely programmable function 2
124 freely programmable function 1
125 Switch unloading level
126 Output speed signal
127 Distance sensor 2 (axle e, f)
128 Distance sensor 1 (axle c, d)
129 ECAS valve block
130 Output steady positive voltage 2
131 Output steady positive voltage 1
132 Output RSS active signal
133 Output ABS active signal
134 Switch road finisher brake
137 Speed switch 2 (ISS 2)
138 Speed switch 1 (ISS 1)
139 Valve residual pressure maintenance for ma-
noeuvre assistance
140 Valve residual pressure maintenance for trac-
tion help
141 Lifting axle valve 2
142 Lifting axle valve 1
Message Explanation
143 Pneumatic control line
144 Supply pressure sensor
145 external ELM
146 external ECAS
148 internal ECAS / Calibration
156 J2497
157 Switch normal level 2
158 Button Lift
159 Button Lower
160 Brake release function
163 Axle load calibration
167 Output Steering axle lock
168 Switch Steering axle lock
170 Output Tilt warning
178 Valve Immobilizer
179 Buzzer Immobilizer
180 Router/Repeater
220 Data link towing vehicle/ Trailer
250 J1708
251 Power supply
253 Parameter setting
254 Trailer modulator
Table: 8-3: System Trailer EBS E, Messages Component
System Trailer EBS E: Type of fault
Message Explanation
00 Value too high
01 Value too low
02 Data is irregular or incorrect
03 Overvoltage / Short circuit to 24 V
04 Undervoltage/ Short circuit to ground
05 Permanent current consumption
06 Current too high or circuit grounded
07 Air gap too big
08 Slip
09 Signal failure
10 Jump up / Jump down
11 see failure note
12 see failure note
13 Characteristic curve error
14 Special faults / See fault info
15 Residual pressure
Table: 8-4: System Trailer EBS E, Messages Fault type
System IVTM: Component
Message Explanation
0639 CAN (short circuit / bus off)
0927 Warning lamp 2 (optional / pin 4)
0928 Warning lamp 1 (standard / pin 2)
0929 Tyre data cannot be analysed
1121 Data on the CAN data bus
