SmartBoard Annex
52
Message Explanation
3011 Pressure in tyre on axle 1, outer wheel left
3012 Pressure in tyre on axle 1, inner wheel left
3013 Pressure in tyre on axle 1, inner wheel right
3014 Pressure in tyre on axle 1, outer wheel right
3021 Pressure in tyre on axle 2, outer wheel left
3022 Pressure in tyre on axle 2, inner wheel left
3023 Pressure in tyre on axle 2, inner wheel right
3024 Pressure in tyre on axle 2, outer wheel right
3031 Pressure in tyre on axle 3, outer wheel left
3032 Pressure in tyre on axle 3, inner wheel left
3033 Pressure in tyre on axle 3, inner wheel right
3034 Pressure in tyre on axle 3, outer wheel right
3041 Pressure in tyre on axle 4, outer wheel left
3042 Pressure in tyre on axle 4, inner wheel left
3043 Pressure in tyre on axle 4, inner wheel right
3044 Pressure in tyre on axle 4, outer wheel right
3051 Pressure in tyre on axle 5, outer wheel left
3052 Pressure in tyre on axle 5, inner wheel left
3053 Pressure in tyre on axle 5, inner wheel right
3054 Pressure in tyre on axle 5, outer wheel right
3111 Leakage at tyre or valve on axle 1, outer wheel
left
3112 Leakage at tyre or valve on axle 1, inner wheel
left
3113 Leakage at tyre or valve on axle 1, inner wheel
right
3114 Leakage at tyre or valve on axle 1, outer wheel
right
3121 Leakage at tyre or valve on axle 2, outer wheel
left
3122 Leakage at tyre or valve on axle 2, inner wheel
left
3123 Leakage at tyre or valve on axle 2, inner wheel
right
3124 Leakage at tyre or valve on axle 2, outer wheel
right
3131 Leakage at tyre or valve on axle 3, outer wheel
left
3132 Leakage at tyre or valve on axle 3, inner wheel
left
3133 Leakage at tyre or valve on axle 3, inner wheel
right
3134 Leakage at tyre or valve on axle 3, outer wheel
right
3141 Leakage at tyre or valve on axle 4, outer wheel
left
Message Explanation
3142 Leakage at tyre or valve on axle 4, inner wheel
left
3143 Leakage at tyre or valve on axle 4, inner wheel
right
3144 Leakage at tyre or valve on axle 4, outer wheel
right
3151 Leakage at tyre or valve on axle 5, outer wheel
left
3152 Leakage at tyre or valve on axle 5, inner wheel
left
3153 Leakage at tyre or valve on axle 5, inner wheel
right
3154 Leakage at tyre or valve on axle 5, outer wheel
right
3410 Tyre pressure deviation left - right on axle 1
3420 Tyre pressure deviation left - right on axle 2
3430 Tyre pressure deviation left - right on axle 3
3440 Tyre pressure deviation left - right on axle 4
3450 Tyre pressure deviation left - right on axle 5
3500 Tyre pressure deviation relative to optimum
values in the tyres of all wheels on the vehicle
Table: 8-5: System IVTM, Messages Component
System IVTM: Type of fault
Message Explanation
00 no description of the detected fault
01 Value above the critical, maximum limit value
02 Value below the critical, minimum limit value
03 Implausible signal
04 No signal
05 Short circuit with ground
06 Short circuit with the supply voltage
07 Value below the specified limit value
08 Invalid signal
09 Device error
10 Interruption
11 Slight drift of the signal value
12 Medium drift of the signal value
13 Large drift of the signal value
14 Value above the specified limit value
15 reserved
Table: 8-6: System IVTM, Messages Fault Type
