Operation
Refueling the Machine 6.20
49
[en-US] | 09/2022 | 5100061327 | RTLx-SC3 | Operator’s Manual
Proper operation of the machine on slopes will prevent rollovers. Read and
follow safety instructions, for further information, see Operating on Slopes on
page 48. If a machine rollover does occur, care must be taken to prevent
damage to the engine. If the machine has rolled over, oil from the engine
crankcase can flow into the combustion chamber, which can severely dam-
age the engine the next time it is started. If the machine has rolled on its
side, immediate steps should be taken to position the machine upright.
A rollover is indicated by the tip-over light which flashes when in the FLASH
LED mode or stays on solid when in the LOCK OUT START mode. For fur-
ther information, see Programming the ECM Tip-over Mode on page 57.
6.20 Refueling the Machine
WARNING
Fire hazard
Fuel and its vapors are extremely flammable. Burning fuel can cause severe
burns.
► Keep all sources of ignition away from the machine while refueling.
► Do not refuel if the machine is positioned in a truck fitted with a plastic
bed liner.
Static electricity can ignite the fuel or fuel vapors.
► Refuel only when the machine is outdoors.
► Clean up spilled fuel immediately.
Requirements
• Machine shut down
• Machine and fuel tank level with the ground
• Fresh, clean fuel supply (For the fuel specification, see Technical Data
on page 83.)
Procedure
1. Remove the fuel cap.
2. Fill the fuel tank up to the base of the neck.
3. Install the fuel cap.
6
