Operation
Changing Drums 6.27
61
[en-US] | 09/2022 | 5100061327 | RTLx-SC3 | Operator’s Manual
• If the joysticks are out of calibration, the signal transmission indicator (2)
will illuminate red and remain lit, and the operating status indicator (3)
will blink.
• If the joysticks are calibrated, the signal transmission indicator will re-
main dark, and the operating status indicator will blink.
Calibration procedure
All four joystick positions must be calibrated before the transmitter can return
to its normal operating mode. Perform the procedure below to calibrate the
joysticks.
1. Press and release the ON-OFF pushbutton to power up the transmitter.
2. Press and hold the ON-OFF pushbutton for approximately three sec-
onds until the operating status indicator illuminates and remains lit. Re-
lease the ON-OFF pushbutton.
3. Press and hold the ON-OFF pushbutton again for approximately three
seconds until the operating status indicator flashes rapidly. Release the
ON-OFF pushbutton.
4. Move the forward/reverse joystick (4) all the way forward and hold it in
place. While holding the joystick, press and release the ON-OFF push-
button—the signal transmission indicator will flash. Release the for-
ward/reverse joystick.
5. Move the forward/reverse joystick all the way backward and hold it in
place. While holding the joystick, press and release the ON-OFF push-
button—the signal transmission indicator will flash. Release the for-
ward/reverse joystick.
6. Move the left/right joystick (5) all the way to the left and hold it in place.
While holding the joystick, press and release the ON-OFF pushbutton
—the signal transmission indicator will flash. Release the left/right joy-
stick.
7. Move the left/right joystick all the way to the right and hold it in place.
While holding the joystick, press and release the ON-OFF pushbutton
—the signal transmission indicator will flash. Release the left/right joy-
stick.
Exiting calibration mode
The transmitter will automatically return to its normal operating mode after
joystick calibration.
Note: If you are unable to exit calibration mode, remove and install the trans-
mitter battery. This will reset the system.
6.27 Changing Drums
The overall width of the drums on this machine is 560mm (22in.). By in-
stalling drum extensions, the user can increase the overall width of the
drums to 820mm (32in.) as needed to accommodate specific job require-
ments.
