1.5 Font Conventions
italic
Names of paths and files are marked in italic.
e.g.: C:\Programs\WAGO-IO-CHECK
italic
Menu items are marked in bold italic.
e.g.: Save
\
A backslash between two names characterizes the selec-
tion of a menu point from a menu.
e.g.: File \ New
END
Press buttons are marked as bold with small capitals
e.g.:
ENTER
< >
Keys are marked bold within angle brackets
e.g.: <F5>
Courier
The print font for program codes is Courier.
e.g.: END_VAR
1.6 Number Notation
Number code Example Note
Decimal 100 Normal notation
Hexadecimal 0x64 C notation
Binary '100'
'0110.0100'
Within ',
Nibble separated with dots
1.7 Scope
This manual describes the modular WAGO-I/O-SYSTEM 750 with the
DeviceNet ECO fieldbus coupler.
Item-No. Description
750-346 DeviceNet ECO fieldbus coupler, 125 kBaud ... 500 kBaud;
digital and analog signals
