18 • The WAGO-I/O-SYSTEM 750
Storage, Assembly and Transport
WAGO-I/O-SYSTEM 750
DeviceNet
2.5 Storage, Assembly and Transport
Wherever possible, the components are to be stored in their original packag-
ing. Likewise, the original packaging provides optimal protection during
transport.
When assembling or repacking the components, the contacts must not be
soiled or damaged. The components must be stored and transported in appro-
priate containers/packaging. Thereby, the ESD information is to be regarded.
Statically shielded transport bags with metal coatings are to be used for the
transport of open components for which soiling with amine, amide and sili-
cone has been ruled out, e.g. 3M 1900E.
2.6 Mechanical Setup
2.6.1 Installation Position
Along with horizontal and vertical installation, all other installation positions
are allowed.
Attention
In the case of vertical assembly, an end stop has to be mounted as an addi-
tional safeguard against slipping.
WAGO item 249-116 End stop for DIN 35 rail, 6 mm wide
WAGO item 249-117 End stop for DIN 35 rail, 10 mm wide
2.6.2 Total Expansion
The maximum total expansion of a node is calculated as follows:
Quantity Width Components
1 50 mm ECO coupler
64 12 mm bus modules
- inputs / outputs
- power supply modules
- etc.
1 12 mm end module
sum 830 mm
Warning
The maximal total expansion of a node must not exceed 830 mm
