100 • I/O Modules
WAGO-I/O-SYSTEM 750
DeviceNet
5.1.2 Digital Output Modules
DO DC 5 V
750-519 4 Channel, DC 5 V, 20mA, short-circuit-protected; high-side switching
DO DC 12(14) V
753-534 8 Channel, DC 12(14) V, 1A, short-circuit-protected; high-side switching
DO DC 24 V
750-501, 753-501 2 Channel, DC 24 V, 0.5 A, short-circuit-protected; high-side switching
750-502, 753-502 2 Channel, DC 24 V, 2.0 A, short-circuit-protected; high-side switching
750-506, 753-506 2 Channel, DC 24 V, 0.5 A, short-circuit-protected;
high-side switching; with diagnostics
750-507, 753-507 2 Channel, DC 24 V, 2.0 A, short-circuit-protected;
high-side switching; with diagnostics; No longer available, replaced by
750-508
750-508 2 Channel, DC 24 V, 2.0 A, short-circuit-protected;
high-side switching; with diagnostics; Replacement for 750-508
750-535 2 Channel, DC 24 V, EEx i, short-circuit-protected;
PNP-positive switching
750-504, 753-504 4 Channel, DC 24 V, 0.5 A, short-circuit-protected; high-side switching
750-531, 753-531 4 Channel, DC 24 V, 0.5 A, short-circuit-protected; high-side switching
750-516, 753-516 4 Channel, DC 24 V, 0.5 A, short-circuit-protected; low-side switching
750-530, 753-530 8 Channel, DC 24 V, 0.5 A, short-circuit-protected; high-side switching
750-537 8 Channel, DC 24 V, 0.5 A, short-circuit-protected; high-side switching;
with diagnostics
750-536 8 Channel, DC 24 V, 0.5 A, short-circuit-protected; low-side switching
DO AC 120(230) V
753-540 4 Channel, AC 120(230) V, 0.25 A, short-circuit-protected;
high-side switching
DO AC/DC 230 V
750-509, 753-509 2 Channel Solid State Relay, AC/DC 230 V, 300 mA
750-522 2 Channel Solid State Relay, AC/DC 230 V, 500 mA, 3 A (< 30 s)
DO Relay
750-523 1 Channel, AC 230 V, AC 16 A, isolated output, 1 make contact, bista-
ble, manual operation
750-514, 753-514 2 Channel, AC 125 V , AC 0.5 A , DC 30 V, DC 1 A,
isolated outputs, 2 changeover contacts
750-517, 753-517 2 Channel, AC 230 V, 1 A, isolated outputs, 2 changeover contacts
750-512, 753-512 2 Channel, AC 230 V, DC 30 V, AC/DC 2 A, non-floating, 2 make con-
tacts
750-513, 753-513 2 Channel, AC 230 V, DC 30 V, AC/DC 2 A, isolated outputs, 2 make
contacts
