WAGO I/O System 750 Series - System Modules

126 • I/O Modules
WAGO-I/O-SYSTEM 750
DeviceNet
5.2.6 System Modules
System Modules with Diagnostics
750-610, -611
The 750-610 and 750-611 Supply Modules provide 2 bits of diagnostics in the
Input Process Image for monitoring of the internal power supply.
Input Process Image
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Diagnostic bit S 2
Fuse
Diagnostic bit S 1
Voltage
The system modules seize 2 Instances in Class (0x65).
Binary Space Module
750-622
The Binary Space Modules 750-622 behave alternatively like 2 channel digital
input modules or output modules and occupy depending upon the selected set-
tings 1, 2, 3 or 4 bits per channel. According to this, 2, 4, 6 or 8 bits are occu-
pied then either in the process input or the process output image.
Input or Output Process Image
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
(Data bit
DI 8)
(Data bit
DI 7)
(Data bit
DI 6)
(Data bit
DI 5)
(Data bit
DI 4)
(Data bit
DI 3)
Data bit
DI 2
Data bit
DI 1
The Binary Space Modules seize 2, 4, 6 or 8 Instances in class (0x65) or in
class (0x66).
