2.6.7 Internal Bus / Data Contacts
Communication between the ECO coupler and the bus modules as well as the
system supply of the bus modules is carried out via the internal bus. It is com-
prised of 6 data contacts, which are available as self-cleaning gold spring con-
tacts.
Fig. 2-7: Data contacts p0xxx07x
Warning
Do not touch the gold spring contacts on the I/O modules in order to avoid
soiling or scratching!
ESD (Electrostatic Discharge)
The modules are equipped with electronic components that may be destroyed
by electrostatic discharge. When handling the modules, ensure that the envi-
ronment (persons, workplace and packing) is well grounded. Avoid touching
conductive components, e.g. gold contacts.
