34 • The WAGO-I/O-SYSTEM 750
Power Supply
WAGO-I/O-SYSTEM 750
DeviceNet
2.7.4 Supply example
Note
The system supply and the field supply should be separated in order to ensure
bus operation in the event of a short-circuit on the actuator side.
750-630750-612 750-410 750-401
750-613
750-512 750-512750-616 750-513 750-610 750-552 750-600750-612 750-616
2) 2)
1)
a)
b)
c)
d)
1)
24V
24V
10 A
10 A
L1
L2
L3
N
PE
230V
230V
Main ground bus
Shield (screen) bus
System
Supply
Field
Supply
Field
Supply
1) Separation module
recommended
2) Ring-feeding
recommended
a) Power Supply
on coupler via external
Supply Module
b) Internal System
Supply Module
c) Supply Module
passive
d)
iagnostics
Supply Module
with fuse carrier/
d
Fig. 2-21: Supply example g0xxx13e
