112 • I/O Modules
WAGO-I/O-SYSTEM 750
DeviceNet
2 Channel Analog Input Modules
750-452, -454, -456, -461, -462, -465, -466, -467, -469, -472, -474, -475, -476,
-477, -478, -479, -480, -481, -483, -485, -492, (and all variations),
753-452, -454, -456, -461, -465, -466, -467, -469, -472, -474, -475, -476, -477,
-478, -479, -483, -492, (and all variations)
Input Process Image
Instance Byte Destination Remark
D0
n
D1
Measured Value Channel 1
D2
n+1
D3
Measured Value Channel 2
The input modules represent 2x2 bytes and seize 2 Instances in Class (0x67).
4 Channel Analog Input Modules
750-453, -455, -457, -459, -460, -468, (and all variations),
753-453, -455, -457, -459
Input Process Image
Instance Byte Destination Remark
D0
n
D1
Measured Value Channel 1
D2
n+1
D3
Measured Value Channel 2
D4
n+2
D5
Measured Value Channel 3
D6
n+3
D7
Measured Value Channel 4
The input modules represent 4x2 bytes and seize 4 Instances in Class (0x67).
