78 • DeviceNet
Process data and Diagnostic Status
WAGO-I/O-SYSTEM 750
DeviceNet
Input 2 (I/O Assembly Instance 8):
The digital input data image is transmitted to the master via the corresponding
I/O message connection. The data length is equivalent to the number of digital
input data and is rounded up to full bytes.
Input 3 (I/O Assembly Instance 9):
The analog input data image is transmitted to the master via the corresponding
I/O message connection. The data length is equivalent to the number of analog
input data in bytes.
