Power Supply Pro 2
You can communicate with the product through the communication interface. The follow-
ing options are available for this:
• Via the WAGO USB Communication Cable (see section Accessories)
• Via an attachable communication module (see section Accessories)
The WAGO USB Communication Cable is intended exclusively for parameterization and
is not designed for continuous communication. Use a corresponding communication mod-
ule for continuous communication!
If you use a communication module, the corresponding communication module is de-
scribed in the & Product Manual.
To connect to a PC with the WAGO USB Communication Cable, perform the following
steps:
1. Remove the cap.
2. Connect the USB connector of the WAGO USB Communication Cable to your PC.
3. Carefully insert the plug for the communication interface straight into the communi-
cation interface in such a way that the keying tab fits into the lower recess.
ð The plug is seated correctly once it has been inserted into the interface up to the
stop. However, since the contours of the housing and plug differ, the plug does
not sit completely flush with the surface of the housing.
You can now connect to your product with the WAGO Interface Configuration software
and configure it (see section 8Configuration [}37]).
3.9 Technical data
3.9.1 Product
Table15: Technical Data – Product
Property Value
Width 50 mm
Height 130 mm
Depth 130 mm (from the top edge of the DIN-rail)
Weight 1000g
Degree of protection IP20
