WAGO Pro 2 - Table 20 Technical Data - Output; Output

2787-2146 (/0000-00x0)Properties
20 Product manual | Version: 1.2.2
Power Supply Pro 2
Property Value
Fine-stranded 0.08 … 2.5 mm² / 28 … 12 AWG
Insulated ferrule with plastic collar 0.25 … 1.5 mm² / 20 … 16 AWG
Ferrule without plastic collar 0.25 … 2.5 mm² / 20 … 14 AWG
Strip length 8 … 9mm / 0.31 … 0.35inch
Specifications of the conductors used ≥ +75°C / +167°F (ambient air temperature: ≤
+60°C / 140°F)
≥ +90°C / 194°F (ambient air temperature: >
+60°C / 140°F)
Required tools (conductor termination) Operating tool, with a partially insulated shaft,
type 2 (see section 8Accessories [}72])
3.9.3 Output
Table20: Technical Data – Output
Property Value
Nominal output voltage 24VDC SELV
1)
Output voltage range 24 … 28 VDC SELV
Nominal output current 10 A (see section Derating)
Output current range 10 … 8.6 A
Output power
2)
240 W
Power Boost 15 A (5 s)
Top Boost 60 A (15 ms)
Derating of output power See section Derating
Line regulation
2)
< 0.02 %
Load regulation
3)
< 2.0 %
Residual ripple/noise
4)
< 70 mV
Overload behavior
5) 6)
“Constant Current” Mode
1)
“Constant Current with Latching Shutdown” Mode
“Hiccup” Mode
“Electronic Circuit Breaker” Mode
“Latching Shutdown on Thermal Overload” Mode
“Power Boost” Mode
“Top Boost” Mode
1)
Factory setting
2)
Nominal load, in range 90 ... 264 VAC
3)
10 % / 90 % load step
4)
20 MHz bandwidth
5)
See section 8Short-Circuit and Overload Behavior [ } 64]
6)
Can be set via the WAGO Interface Configuration software
7)
See figure “Turn-on Time”
