9Diagnostics
9.1 Diagnostics via Indicators
The product has an optical status indicator. This indicator consists of five LEDs.
These LEDs indicate operating states and diagnostics.
Table45: Display of Diagnostics – Warnings
Indicator Output Voltage Too Low Output Voltage Too High Overload Threshold or Trip-
ping Current of Electronic Cir-
cuit Breaker Exceeded
>100% Flashing (2Hz) Flashing (2Hz) Flashing (2Hz)
>75% Off Flashing (2Hz) Signaling of regular utilization
>50% Off Off
>25% Off Off
DC OK Flashing (2Hz) Off
Table46: Diagnostic Indicators – Errors
Indicator Short Circuit at Out-
put
Overtemperature
Shutdown
1)
Internal Product
Fault
Communication inter-
face
>100% Flashing (8Hz) Flashing (8Hz) Flashing (8Hz) Flashing (8Hz)
>75% Off Steady Flashing (8Hz) Off
>50% Off Off Flashing (8Hz) Off
>25% Off Off Flashing (8Hz) Off
DC OK Off Off Flashing (8Hz) Steady
1)
Automatic restart (factory setting)
