2787-2146 (/0000-00x0) Functions
Product manual | Version: 1.2.2 29
Power Supply Pro 2
4Functions
4.1 Functions
The product has the following integrated functions:
Table40: Functions
Function Description
Top Boost Supplies up to 600 % more output current for 15ms.
Power Boost Supplies up to 150% of the output current for 5s.
Recording and displaying measured values For details, see section Display Section: Measured Values.
Recording and displaying time series of
measured values
For details, see section Display Section: Measurement Recording.
Configurable overload behavior For details, see section Dialog:Settings.
Configurable DI/DO interface For details, see section Dialog:Settings.
Configurable load management For details, see section Dialog:Settings.
Communication interface Allows connection via a WAGO USB Communication Cable (see
section Communication Interface) or via a communication module
that is available as an option.
The communication modules allow configuration and monitoring
of the product via fieldbus systems.
4.2 Overvoltage protection
The product is protected against overvoltage. For insulation testing on your electrical
equipment, this protection can be removed. The following test voltages apply:
Table41: Test voltages on the input side
Overvoltage Protection Test voltage
Input > 600 VDC
> 420 VAC
How to enable and disable overvoltage protection is described in Section 8Enable/Dis-
able Input-Side Overvoltage Protection [}62].
Table42: Test voltages on the output side
Overvoltage Protection Test voltage
Output > 225 VDC
> 175 VAC
How to enable and disable overvoltage protection is described in Section 8Enable/Dis-
able Output-Side Overvoltage Protection [}62].
You can find explicit information on maximum insulation voltages in the Section Safety.
